Clicktronic
YUV Component Cable
RCA cable for YUV image transmission
/7
Product and packaging similar. Subject to modifications and errors.
Clicktronic
YUV Component Cable
RCA cable for YUV image transmission
Article details
Maximize the potential of your display screen. The YUV component cable separates each piece of color information into two components which are luminance (luminous intensity, luma), and chrominance (color component, chroma). Due to multiple signal shielding, pure materials, and precise workmanship this cable transmits any analog video signal picture for picture with low noise, color fidelity, and clarity.
  • 75 Ω defined characteristic impedance
  • pure copper conductor and 2-way shielding for clear signal quality
  • 24 carat gold-plated contacts for minimum transmission resistance
Technical specifications
Connections
Connection, contact material
gold (24 kt)
Connection, housing material
ABS, PVC
Connection, shielding
yes
Latch protection
no
Connection type
RCA Female
Connection, length
39.8 mm
Connection, type
3 RCA male (YUV/RGB)
Connection 2, type
3 RCA male (YUV/RGB)
Kink protection
both sides
Cable
Cable type
round cable
Cable length
10 m
Inner conductor material
CU (copper)
AWG
24
Type 2, shielding
braid (copper) 64x
Material cable sheath
PVC
Ferrite core
no
Signal transmission
Signal amplification
no
Capacity
60 pF
Impedance
75 Ω
max. bandwidth
10 MHz
General
Markings
WEEE, CE
Operating temperature from
-10 °C
Operating temperature up to
80 °C
Warranty
10 years
Packaging type
Dimensions / Weight
Consumption Unit
1 pc. in cardboard box
Downloads
Declaration of conformity pdf
€54.99 RRP
Packing units:
1 / 8
Packaging type
Cable length
3 m
10 m
Item: 70427
EAN: 4040849704277
