Ultra-Slim High Speed HDMI™ Cable with Ethernet
4K/60Hz
Ultra-Slim High Speed HDMI™ Cable with Ethernet
4K/60Hz
Article details
Clicktronic attaches great importance to durability and stability. Our quality promise: 10-year warranty on our HDMI™ cables. The proprietary construction of our connection cables makes them extremely robust. The three-part connector construction made of PVC and ABS components compensates for jerky pulling on the cable, making it ideally protected against cable breakage. High-quality, gold-plated contacts and pure copper conductors transmit audio and video signals in maximum quality for a perfect home cinema and gaming experience. The Clicktronic Ultra-Slim HDMI™ High-Speed cable enables a razor-sharp picture and has an extremely fast transmission speed.
- Ultra-Slim HDMI™ high-speed cable connects TVs and monitors to e.g. laptops, projectors, beamers or game consoles such as PlayStation or Xbox for flawless movie and gaming experiences.
- UHD signal transmission with up to 4K @ 60 Hz (2160p) and Full HD @ 60 Hz (1080p)
- Extra-slim HDMI™ connection cable for high flexibility when connecting and with max. transfer rate of up to 18 Gbit/s
- 24-carat gold-plated HDMI™ connectors and advanced technology guarantee flawless signal quality without image transmission delays for an optimal gaming experience.
- Pure copper conductors and 3-fold shielding for clear sound and pin-sharp video and picture quality
- Clicktronic 4K cable with HDMI™ Premium certification guarantees best quality.
- HDMI™ connection for all common features such as ARC (audio return channel), HDCP or 3D content
Technical specifications
Labelling
Disclaimer
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade Dress and
the HDMI Logos are trademarks or registered trademarks of HDMI Licensing
Administrator, Inc.
Connections
Connection, contact material
gold (24 kt)
Connection, housing material
ABS, PVC
Connection, shielding
yes
Connection type
HDMI™ connector male (type A)
Connection, type
HDMI™ connector male (type A)
Connection 2, type
HDMI™ connector male (type A)
Kink protection
both sides
Cable
Cable type
round cable
Cable length
1.5 m
Cable sheath diameter (approx.)
4.5 mm
Inner conductor material
CU (copper)
Cable structure
19+1
AWG
34
Number of shieldings
3 x
Type 1, shielding
braid (copper) 16x
Type 2, shielding
foil (aluminium)
Type 3, shielding
foil (aluminium)
Material cable sheath
PVC
Ferrite core
no
Signal transmission
Signal amplification
no
Insulation resistance
10 MΩ/km
Supported video standards
4K/60Hz (3840 x 2160) UHD
other supported standards
HDR (High Dynamic Range), 3D, HDCP 2.2
supported audio standards
Audio Return Channel (ARC)
max. transmission rate
18 Gbit/s
max. bandwidth
640 MHz
General
Markings
WEEE, CE, ULTRAHD 4K@50/60 Hz, HDMI™ High Speed with Ethernet
Operating temperature from
-10 °C
Operating temperature up to
80 °C
Warranty
10 years
Packaging type
Retail Box
Dimensions / Weight
Consumption Unit
1 pc. in cardboard box
Downloads
Packing units:
1 / 20 / 40
Item: 70703
EAN: 4040849707032
