HDMI™ to Micro HDMI™ Adapter Cable
4K/30Hz
HDMI™ to Micro HDMI™ Adapter Cable
4K/30Hz
Article details
Clicktronic attaches great importance to durability and stability. Our quality promise: 10-year warranty on our HDMI™ cables. The proprietary construction of our connection cables makes them extremely robust. The three-part connector construction made of PVC and ABS components compensates for jerky pulling on the cable, making it ideally protected against cable breakage. High-quality, gold-plated contacts and pure copper conductors transmit audio and video signals in maximum quality for a perfect home cinema and gaming experience. The HDMI™-to-Micro HDMI™ adapter cable enables a crisp picture and has a fast transmission speed.
- HDMI™-to-Micro-HDMI™ cable connects TVs and monitors e.g. to mobile devices such as tablets, digital cameras or camcorders.
- UHD signal transmission with up to 4K @ 30 Hz (2160p) and Full HD @ 60 Hz (1080p)
- HDMI™ connection cable with max. transfer rate of up to 10,2 Gbit/s
- 24-carat gold-plated HDMI™ connectors and advanced technology guarantee flawless signal quality without image transmission delays for an optimal entertainment experience.
- 2-fold shielding and inner conductor made of 99.9 % oxygen-free copper for crystal-clear sound and pin-sharp video and picture quality
- Clicktronic 4K HDMI™ cable for all common features such as ARC (audio return channel), HDCP or 3D content
Technical specifications
Labelling
Disclaimer
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade Dress and
the HDMI Logos are trademarks or registered trademarks of HDMI Licensing
Administrator, Inc.
Connections
Kink protection
both sides
Connection type
HDMI™ connector male (type A), HDMI™ Micro male (type D)
Connection, housing material
ABS, PVC
Connection, contact material
gold (24 kt)
Connection, shielding
yes
Connection, type
HDMI™ connector male (type A)
Connection 2, type
HDMI™ Micro male (type D)
Cable
AWG
32
Cable sheath diameter (approx.)
5 mm
Number of shieldings
3 x
Cable type
round cable
Material cable sheath
PVC
Inner conductor material
CU (copper)
Type 1, shielding
braid (copper) 16x
Type 2, shielding
foil (aluminium)
Type 3, shielding
foil (aluminium)
Cable length
5 m
Signal transmission
Max. resolution
4K/30Hz (3840x2160) UHD
max. transmission rate
10.2 Gbit/s
General
Markings
WEEE, CE, HDMI™ High Speed with Ethernet, ULTRAHD 4K@50/60 Hz
Operating temperature up to
80 °C
Operating temperature from
-10 °C
Warranty
10 years
Packaging type
Retail Box
Dimensions / Weight
Consumption Unit
1 pc. in cardboard box
Downloads
Packing units:
1 / 12 / 24
Item: 70330
EAN: 4040849703300
