CAT 6 Outdoor Network Cable, U/UTP, black
copper conductor (CU), AWG 23/1 (solid), polyethylene cable sheath (PE)
CAT 6 Outdoor Network Cable, U/UTP, black
copper conductor (CU), AWG 23/1 (solid), polyethylene cable sheath (PE)
Article details
The Goobay network cable is ideal for outdoor use, e.g. in the garden, for camping, on building facades and for connecting surveillance cameras. The stable cable sheath made of polyethylene is extremely resistant to weathering and UV radiation.
- Unshielded twisted-pair LAN cable for outdoor installation
- Unterminated patch cable for assembly and installation with LSA connection technology. No approval for permanent installation in buildings.
- Flexible, unterminated data and installation cable for outdoor use .
- Double-layer polyethylene (PE) jacket protects the network cable outdoors and makes it extremely weather-resistant.
- The outdoor Ethernet cable is ideal for use in building facades and surveillance cameras.
- High-quality copper conductor (CU) guarantees an excellent, powerful network connection.
- CAT 6 network cable is suitable for Gigabit Ethernet with speeds of up to 10/100/1000 Mbit/s, Power over Ethernet (PoE, PoE+, UPoE and 4PPoE) and HDBaseT.
Technical specifications
Cable
Specification
CAT 6
Shielding class
U/UTP
AWG
23/1 (solid)
Diameter of insulated conductor
1.01 mm (+/-0.05)
Fire class (CPR)
Fca
Meter scaling
Cable length
100 m
Cable type
outdoor cable
Inner conductor material
CU (copper)
Material cable sheath
PE
Cable sheath diameter (approx.)
6.2 mm
Signal transmission
max. bandwidth
250 MHz
usable up to cable length
90 m
Impedance
100 Ω
General
Color
black
Markings
FCA_CPR, CE
Operating temperature from
-20 °C
Operating temperature up to
75 °C
Packaging type
Cable ring-coil
Dimensions / Weight
Consumption Unit
1 pc. cable reel
Downloads
Packing units:
1 / 2
Item: 77625
EAN: 4040849776250
