CAT 6 network cable, S/FTP (PiMF), grey
copper-clad aluminium wire (CCA), AWG 23/1 (solid)
Product and packaging similar. Subject to modifications and errors.
CAT 6 network cable, S/FTP (PiMF), grey
copper-clad aluminium wire (CCA), AWG 23/1 (solid)
Article details
Our CAT cables transmit signals in top quality at high speed, always guaranteeing a stable connection. High-quality inner conductors, robust cable sheathing and precisely fitting plugs distinguish our portfolio of connection cables and plugs. Our solutions are especially suitable for high-resolution image transmission in 8K @ 60 Hz and 4K @ 120 Hz. Goobay always provides the perfect products for your network needs - whether you aim to set up a home or company network. Simply. All. You need!
- Double-shielded twisted-pair LAN cable for the small office and working from home (SOHO and WFH applications)
- Unterminated patch cable for assembly and installation with LSA connection technology
- Flexible, unterminated data and installation cable for indoor use with a maximum transmission length of 40 m
- S/FTP overall shield: aluminium foil shield for individual wire pairs (PiMF) and aluminium braid shield for the cable sheath
- High-quality copper-clad aluminium wire (CCA) and double shielding guarantee an excellent, powerful network connection.
- Sturdy PVC jacket effectively protects the Ethernet cable from breakage.
- Complies with the Construction Products Regulation (CPR) and Eca fire protection class
Technical specifications
Cable
Cable type
round cable
Cable length
100 m
Material cable sheath
PVC
Cable sheath diameter (approx.)
6.3 mm
Specification
CAT 6
Diameter of insulated conductor
1 mm (+/-0.05)
Shielding class
S/FTP (PiMF)
Meter scaling
Fire class (CPR)
Eca
Inner conductor material
CCA (copper-clad aluminium)
Number of shieldings
2 x
Type 1, shielding
foil (alu) PiMF
Type 2, shielding
braid (alu) overall shield
AWG
23/1 (solid)
Signal transmission
usable up to cable length
40 m
max. bandwidth
250 MHz
Impedance
100 Ω
General
Color
grey
Markings
ECA_CPR, CE, SOHO
Packaging type
Cable spool-drum
Dimensions / Weight
Consumption Unit
1 pc. cable reel
Downloads
Packing units:
1 / 4
Item: 93955
EAN: 4040849939556
