CAT 6 network cable, S/FTP (PiMF), grey
copper-clad aluminium wire (CCA), AWG 26/7, PVC cable sheath
CAT 6 network cable, S/FTP (PiMF), grey
copper-clad aluminium wire (CCA), AWG 26/7, PVC cable sheath
Article details
Our CAT cables transmit signals in top quality at high speed, always guaranteeing a stable connection. High-quality inner conductors, robust cable sheathing and precisely fitting plugs distinguish our portfolio of connection cables and plugs. Our solutions are especially suitable for high-resolution image transmission in 8K @ 60 Hz and 4K @ 120 Hz. Goobay always provides the perfect products for your network needs - whether you aim to set up a home or company network. Simply. All. You need!
- Unterminated, double-shielded LAN cable for the small office and working from home (SOHO and WFH applications)
- S/FTP overall shield: aluminium foil shield for individual wire pairs (PiMF) and aluminium braid shield for the cable sheath
- Flexible, unterminated twisted pair data cable for indoor use with a maximum transmission length of 20 m
- High-quality copper-clad aluminium wire (CCA) and double shielding guarantee an excellent, powerful network connection.
- Sturdy PVC jacket effectively protects the Ethernet cable from breakage.
- Complies with the Construction Products Regulation (CPR) and Eca fire protection class
Technical specifications
Cable
Specification
CAT 6
Shielding class
S/FTP (PiMF)
AWG
26/7 (stranded)
Diameter of insulated conductor
1.05 mm (+/-0.05)
Fire class (CPR)
Eca
Cable length
100 m
Cable type
round cable
Inner conductor material
CCA (copper-clad aluminium)
Material cable sheath
PVC
Cable sheath diameter (approx.)
6.3 mm
Number of shieldings
2 x
Type 1, shielding
foil (alu) PiMF
Type 2, shielding
braid (alu) overall shield
Signal transmission
max. bandwidth
250 MHz
usable up to cable length
20 m
Impedance
100 Ω
General
Color
grey
Markings
ECA_CPR, CE, SOHO
Packaging type
Cable spool-drum
Dimensions / Weight
Consumption Unit
1 pc. cable reel
Downloads
Packing units:
1 / 2 / 4
Item: 93953
EAN: 4040849939532
